Home Professional AudioProfessional Amplifier2 Channels Class-D Amplifier Dual-Channel Digital Power Amplifier (1U) PV2015 PV2020 PV2030

2*150W ; 2*200W ; 2*300W

Dual-Channel Digital Power Amplifier (1U)

PV2015 PV2020 PV2030
  • Dual-channel stereo professional power amplifier.
  • Brand-new appearance design with an extremely compact 19-inch chassis, only 1U high (44mm), suitable for standard rack installation.
  • A range of small and medium-power amplifier options to meet different requirements.
  • Adjustable input sensitivity: 0.775V, 1V, 1.44V.
  • Three selectable output modes: dual-channel, mono, and BTL bridge, with an output mode switch.
  • Independent volume control for each channel.
  • Minimum load impedance: 4Ω in stereo mode, 8Ω in BTL mode.
  • Equipped with XLR signal input interfaces for flexible and convenient use.
  • Three commonly used professional SPEAKON speaker connectors for amplifier output.
  • Protection and alarm functions including short-circuit protection, DC protection, and power on/off protection.
  • LED indicators for each channel showing operating status, designed for low noise.
  • Suitable for speech transmission and sound reinforcement in various applications.
Overview Specifications Brochure Related Products Solutions Latest News & Cases

The PV2015, PV2020, and PV2030 series is a 1U dual-channel digital power amplifier range engineered to deliver flexible power options for small to medium-scale sound reinforcement applications. Featuring a compact chassis and multiple operating modes—including stereo, parallel, and bridge—the series adapts readily to various system configurations. It offers adjustable input sensitivity and robust connectivity via XLR and SPEAKON interfaces, ensuring seamless integration with professional audio systems. Enhanced by reliable protection circuitry and independent channel control, the series provides clear, stable performance for speech and general-purpose sound reinforcement.


Specifications of 2*150W 2*200W 2*300W Dual-Channel Digital Power Amplifier (1U) PV2015 PV2020 PV2030


Model

PV2015

PV2020

PV2030

Rated Output (Dual Channel, 8Ω)

2*150W

2*200W

2*300W

Rated Output (Dual Channel, 4Ω)

2*225W

2*300W

2*450W

Rated Output (Bridged Mode, 8Ω)

450W

600W

900W

Output Mode

Stereo, Parallel, Bridge

Signal-to-Noise Ratio

≥95dB (A-weighted)

Input Sensitivity

0.775V/1V/1.44V

Frequency Response

20-20KHz (±2dB)

Distortion (Normal Operating

Conditions, Stereo 8Ω, 1KHz)

≤0.3%

Power Supply Range

AC220-230V 50/60Hz

Protection

Over-current, over-temperature, short-circuit

Net Weight

3.8kg

3.8kg

4.2kg

Product Dimensions

483×240×44mm

Package Dimensions

550×375×120mm
