Home ProductsCommercial Amplifier & ControllerClassical Commercial Amplifier 250W Professional PA Mixer Amplifier MP6224II

250W / 40Ω (100 V) 20 Ω (70 V)

250W Professional PA Mixer Amplifier

MP6224II
  • Commercial-grade high-performance integrated mixer amplifier
  • Equipped with 2 microphone, 2 auxiliary and 1 telephone input channels, each with independent volume control
  • 2 electronically-balanced mic inputs, 2 line-level auxiliary inputs and 1 auxiliary line output.
  • Switchable phantom power for MIC 1 and MIC 2, plus dedicated Zone 2 output with individual gain adjustment
  • Includes master volume control, comprehensive tone control with ±10 dB adjustment range for bass and treble
  • Multi-impedance speaker outputs: 70V, 100V constant voltage and 4-16 Ω low impedance
Overview Specifications Related Products Solutions Latest News & Cases

The MP6224II represents a premium-grade, high-performance commercial integrated mixer amplifier, engineered specifically to address public address, voice paging and background music playback requirements. It is exceptionally well-suited for a wide range of environments including educational institutions, corporate offices, retail shops, manufacturing facilities, mosques, churches and large indoor spaces, delivering crystal-clear, consistent audio performance to fulfill the rigorous demands of professional audio applications.



Model

MP6224II

Rated Power

250 W

Power Consumption

250 W (EN60065), 550 W at rated output (AC)

Frequency Response

50Hz – 20 kHz (±3 dB)

Distortion

≤1% at 1 kHz, 1/3 rated power

Input

MIC1 & MIC2: -46 dBV, 600 Ω, balanced, phoenix terminal (3.81 mm barrier spacing)

TEL: -10 dBV, 10 kΩ, balanced, phoenix terminal (3.81 mm barrier spacing)

AUX1 & AUX2: -10 dBV, 10 kΩ, unbalanced, RCA jack

Output

Speaker out: Balanced (floating), M3 screw terminal, distance between barriers: 7.62 mm (0.3")
High impedance: 40Ω (100 V), 20 Ω (70 V)
Low impedance: 4 Ω (31.6 V)
Auxiliary out: 0 dBV, 600 Ω, unbalanced, RCA jack

Tone Control

Bass: ±10 dB at 100 Hz
Treble: ±10 dB at 10 kH

Signal to Noise Ratio

≥65 dB

Power Source

220V AC

Phantom Power

DC +48V±3 (MIC 1&MIC2)

Muting

MIC1, MIC2, and TEL feature a priority function that attenuates AUX1 and AUX2 input signals by 30 dB;

Sensitivity for MIC1, MIC2, and TEL is adjustable;

MIC1, MIC2, and TEL have equal priority.

Finish

Panel: Aluminium alloy, black & white
Enclosure: Metal plate, black

Dimensions

430 (W) × 88 (H) × 374 (D) mm (16.93" × 3.46" × 14.72")

Weight

13.51kg
