Home Professional AudioProfessional Amplifier2 Channels Class-D Amplifier 2-Channel Stereo Conference Mixer Amplifier D2030 D2045 D2060 D2080 D2100 D2130 D2160

300W ; 450W ; 600W ; 800W ; 1000W ; 1300W ; 1600W

2-Channel Stereo Conference Mixer Amplifier

D2030 D2045 D2060 D2080 D2100 D2130 D2160
  • Professional stereo conference amplifier.
  • Dual-channel independent output with stereo and parallel modes.
  • Selectable input gain options for compatibility with various signal sources.
  • Built-in noise gate to suppress background noise.
  • Comprehensive protection against thermal overload, overcurrent, short circuit, and power-on/off transients.
  • High damping factor ensures tight and accurate low-frequency control.
  • Professional XLR balanced inputs and Speakon speaker outputs.
Overview Specifications Related Products Solutions Latest News & Cases

This series of two-channel professional power amplifiers offers a wide power range from 300W to 1600W, featuring a highly reliable amplifier circuit and a robust power supply design. Supporting stereo and parallel operating modes, the series delivers excellent dynamic performance, precise sound control, and stable output, making it ideal for conference systems, fixed installations, commercial sound reinforcement, and small to medium-sized live sound applications.


Specifications of 300W 450W 600W 800W 1000W 1300W 1600W 2-Channel Stereo Conference Mixer Amplifier D2030 D2045 D2060 D2080 D2100 D2130 D2160


Model

D2030

D2045

D2060

D2080

D2100

D2130

D2160

Power Specifications

EIA

AC220V

OutputPower

1kHz

Max. THD 1%

TestMono

8Ω

300W

450W

600W

800W

1000W

1300W

1600W



4Ω

400W

600W

800W

1200W

1500W

2000W

2500W

Electrical Specifications

Amplifier

Gain

0.775V (41dB) / 38dB / 35dB / 32dB



Impedance

20kΩ (balanced, stereo) 10kΩ (unbalanced, parallel)

Frequency Response

＜±0.5dB (8Ω 30W 20-20kHz)

Slew Rate

＞20V/us (8Ω 1kHz)

Damping Factor

＞300 (8Ω 1kHz)

Crosstalk

＞60dB (8Ω 1kHz)

S/N Ratio

＞100dB (A-weighted)

Total Harmonic Distortion (THD+N)

＜0.05% (8Ω 30W)

Inter-Modulation Distortion (IMD)

＜0.3% (8Ω 30W)

General Specifications

Protections

Amplifier

Power on/off protection

Transistor thermal protection

Short circuit protection

Sensor for current on outputs

Limiter



Speakers



Controls

Front Panel

On/Off switch

Signal level control for each channel



Back Panel

Stereo/Parallel selector

Input gain adjust

Indicators

Power: 1 blue; Protect: 2 red; Clip: 2 yellow; Signal: 2 blue.

Connectors

Input

Two Neutrik XLR connectors each channel



Output

1 NeutrikSpeakon + 1 Binding-Post connector each channel

Power Supply

See label on the apparatus

Dimensions (W×H×D)

483×88×447mm (with handles)

483×88×481mm (with handles)

Weight

16.5kg

17.0kg

17.5kg

18.0kg

18.0kg

21.0kg

23.0kg
