Home Professional AudioProfessional SpeakerProfessional Waterproof Speaker 8-Inch 150W Outdoor Two-Way Full Range Loudspeaker D6563F

8" Bass×1, 1.35" Treble×1 ; 80 Hz -18,000Hz ; 150W

8-Inch 150W Outdoor Two-Way Full Range Loudspeaker

D6563F
  • All-weather design with phase-inverted bass-reflex two-way loudspeaker system.
  • Enclosure finished with waterproof polyurea coating; metal grille backed with acoustic damping material.
  • Three top-mounted suspension points enable vertical hanging using rigging rings and ropes in conjunction with rear suspension points.
  • Two rear and side mounting points accommodate D3A wall-mount bracket installation.
  • Bottom slot supports D5A wall-mount bracket or D6A floor-standing tripod mounting.
Overview Specifications Related Products Solutions Latest News & Cases

The D6563F is a professional 8-inch two-way loudspeaker engineered for clear and powerful sound reinforcement. It features an all-weather, waterproof polyurea-coated enclosure with a phase-inverted design for enhanced low-frequency performance. Multiple mounting options—including wall, ceiling suspension, and floor stand—offer flexible installation, while its high sensitivity and 90° × 40° coverage ensure robust and uniform sound distribution for a variety of fixed installation applications.


Specifications of 8-Inch 150W Outdoor Two-Way Full Range Loudspeaker D6563F


Model

D6563F

Unit

8" Bass×1, 1.35" Treble×1

Frequency Response (±3dB)

80 Hz -18,000Hz

Sensitivity

95±2dB

Max. SPL

117±2dB

Input Impedance

8Ω

Rated Power

150W

Directivity (H×V)

90°× 40°

Dimensions (H×W×D)

430×240×235mm

Weight

9.7kg
