Home Commercial AudioCommercial SpeakerCommercial Column Speaker 200W 4.5" Commercial Surface-Mount Column Speaker DSP5420

200W 4.5"x4 8Ω

200W 4.5" Commercial Surface-Mount Column Speaker

DSP5420
  • The DSP5210 series includes multiple models, each with a different number of speaker units and tweeters to suit various audio requirements and application scenarios.
  • Constructed from high-quality aluminum alloy, the series is stable, durable, and well suited for a range of decorative environments.
  • A 4.5" full-range driver paired with a 1" tweeter delivers focused sound energy and exceptional clarity.
  • Sensitivity ranges from 88dB to 90dB, rated power from 100W to 600W, and maximum SPL reaches up to 117.8dB — making these speakers ideal for applications demanding high volume and clear reproduction.
  • The coverage angle is designed at 140° horizontal by 20° vertical, ensuring both sound clarity and uniformity while optimizing the spatial sound field.
Overview Specifications Brochure Related Products Solutions Latest News & Cases

The DSP5420 200W 4.5” Commercial Surface-Mount Column Speaker is a high-power wall-mounted PA solution designed for clear voice projection and wide sound coverage in commercial environments. Featuring advanced 4.5-inch drivers and a durable surface-mount enclosure, it delivers excellent speech intelligibility, strong output, and stable performance for public address systems. Ideal for large indoor spaces such as conference halls, schools, offices, shopping centers, and transportation facilities requiring powerful and reliable audio distribution.


Specifications of 200W 4.5" Commercial Surface-Mount Column Speaker DSP5420


Model

DSP5210

DSP5420

DSP5630

DSP5840

DSP1260

Speaker
Unit

Full-range

4.5"x2

4.5"x4

4.5"x6

4.5"x8

4.5"x12

Tweeter

1"x1

1"x1

1"x1

1"x1

1"x1

Rated Power (RMS)

100W

200W

300W

400W

600W

Impedance

8Ω

8Ω

8Ω

8Ω

8Ω

Freq.Response

120-18KHz

120-18KHz

110-18KHz

110-18KHz

95-18KHz

Sensitivity

88dB

89dB

90dB

90dB

90dB

Maximum SPL

108dB

112dB

114.7dB

116dB

117.8dB

Coverage Angle

140°(H)×20°(V)

140°(H)×20°(V)

140°(H)×20°(V)

140°(H)×20°(V)

140°(H)×20°(V)

Dimension(LxWxH)

123*142*393mm

123*142*653mm

123*142*912mm

123*142*1166mm

123*142*1687mm

Net Weight

3.84KG

6.46KG

9.02KG

11.65KG

16.63KG
