Home Professional AudioProfessional SpeakerActive Professional Speaker 350W Active 12-Inch Full-Range Professional Loudspeaker D6535A

12" bass×1, 1.4” tweeter x1 ; 62Hz –18,000Hz ; 350W（AES）

350W Active 12-Inch Full-Range Professional Loudspeaker

D6535A
  • Rated Power: 350W
  • Driver Configuration: 12" woofer × 1, 1.4" tweeter × 1
  • Frequency Response: 62Hz – 18kHz
  • Sensitivity: 97±2dB
  • Maximum SPL: 123±2dB
  • High-peak-capacity switch-mode power supply (SMPS)
  • Class-D independent power amplifier module
  • Equipped with one XLR input and one XLR output
  • Qualcomm filter with selectable range: 20Hz–400Hz
  • Optimized for mobile applications
  • Dual professional power interface
Overview Specifications Related Products Solutions Latest News & Cases

The D6535A is a professional active conference loudspeaker powered by a high-peak-capacity switch-mode power supply (SMPS) coupled with a dedicated Class-D power amplifier module. The system delivers rich even-order harmonics and mellow tonal quality, with pure and natural sound reproduction. It is well suited for performances, conferences, public squares, shopping malls, and similar applications.


Specifications of 350W Active 12-Inch Full-Range Professional Loudspeaker D6535A


Model

D6535A

DriveUnit

12" bass×1, 1.4” tweeter x1

Freq.Response

62Hz –18,000Hz

SpeakerSensitivity

97±2dB

Max. SPL

123±2dB

Active Signal InputImpedance

20 kΩ

AmplifierPower

500W

Speaker Continuous Power

350W（AES）

Directivity (HxV)

90°×60°

AmplifierDistortion

＜0.05%

Damping Coefficient

＞250

Working Voltage

AC220V/50Hz

Dimensions (Height ×Width ×Depth)

580mm×380mm×372mm

Weight

21kg
